Ponds - review

Landscape and Garden Product Directory

Every garden needs a pond. If not for use or ornament then to satisfy the demands of sustainable water management. Water should be detained and infiltrated as close as possible to the point where it falls.

In other circumstances, it is necessary to line the hollow with a water-retaining layer. It might be of concrete, butyl, metal or clay. Fiberglass is popular, but it is ugly. There are many pond kits on the market.

Water retention alternatives for ponds

• natural retention: if the water table is high, or the soil is clay and water is plentiful, then forming a hollow will be enough to create a pond. The height of the water-table should be investigated by digging a trial pit and, if possible, observing it for 12 months
• a flexible rubber or plastic pond liner: this is a relatively cheap and popular way of forming a pond. The points to watch are (1) pond liners are vulnerable to damage (2) pond liners are ugly if visible. The solution is to bury the pond liner beneath protective layers, which can be (1) matting (2) geotextile (3) sand (4) mud [or a combination of these layers}
• a rigid fiberglass pond liner: this is significantly more durable than a flexible pond liner. Precast fiberglass ponds are available in garden centres. They tend to be ugly, expensive and are more difficult to conceal than flexible pond liners. In situ cast fiberglass is better, but even more expensive.
• waterproof concrete: high-strength structural concrete [a 1:2:4 mix] is waterproof. But the pond needs to be well detailed. If the pond is large it will require expansion joints, waterbars and reinforcement. Concrete is also ugly if visible.
• lead pond liner. A traditional practive was to use stone to form the shape of a rectantular pond or canal and then to line the structure with lead sheeting. This is expensive for a large pond but remains an excellent solution for a small pond. Lead sheeting is sold in rolls for roofing and can be jointed with a special lead-jointing mastic. The shape of the pool can be formed with cheap concrete blocks or soil-cement.
• puddled clay. If the subsoil is clay it can be 'puddled' by tramping it when wet to produce a smooth and waterproof layer. Clay for puddling can also be imported. Clay puddled in layers to a depth of 0.5 to 1.0 metres was used in canal building. A potential problem with clay is that if it is allowed to dry then it cracks.

• about 2 years ago Jessica said

  Can anyone tell me more about lead pond liners and the mastic used to seal one? I want to build a mostly above ground pond with a seat wall, it would be block with stucco on the outside and a capstone, so lead might be perfect. We had thought about shotcrete, as done in swimming pools here, but the lead might be something we could actually do ourselves?

  We're in Arizona, if that makes any difference.

  jwsiddall@aol.com

• about 2 years ago Anonymous said

  Lead???? Aren't we trying to get away from the use of lead?

• about 3 years ago Pond Pumps said

  A pond pump is also an essential part of pond management and maintenance such as filter pond pumps that can pump free floating debris such as plant matter, leaves, pebbles, blanket weed from the pool and pass it to a filter system, thus keeping your pond clear.
